- Advanced CNC Supporting the precise and complex mathematical calculation.
- 4 axes interpolation movement and various automation solution.
- Uniquely designed machine structure to provide high reliable rigidity.
- Thermal strain prevention technology for rapid chip removal.
- Torque motor table as part axis with encoder for closed loop control.
- Stable and reliable design of hob spindle gear box.
- Special clamping system suitable for high-duty cutting.
| CNC Hobbing Machine |
|---|
| TN-100 | TN-150/180 |
| Workpiece |
| Max. Part(OD.x Mod.) | Ф100mm × M2.5 | Ф150/180mm × M4 |
| Max. Helix Angle | -65°/+90° | ±45° |
| Part Table Diameter | Ф90mm | Ф150/180mm |
| Cutting Hob |
| Spindle Nose Taper | BT#30 | BT#40 |
| Max. Hob Size (OD.x L) | Ф65mm x 100mm *1 | Ф120mm x 200mm |
| Max. Hob Shift Stroke | 100mm | 180mm |
| Motion Parameter |
| Hob Spindle (B axis) | Max.4000/6000rpm | S1=22Nm S3=54Nm | Max.2500rpm | S1=115Nm S3=143Nm |
| Table Rotation (C axis) | 1000/2000rpm | 60Nm | 300/600rpm | 270/600Nm |
| Radial Feed (X axis) | Max.5000mm/min | 80mm (10-90mm) | Max.5000mm/min | 180mm(15-195mm) |
| Tangential Feed (Y axis) | Max.3000mm/min | 100mm (55-155mm) | Max.1500mm/min | 180mm(0-180mm) |
| Axial Feed (Z axis) | Max.5000mm/min | 300mm (160-460mm) | Max.5000mm/min | 250mm(150-400mm) |
| Helix Angle (A axis) | Max.720deg/min | ±45° | Max.720deg/min | ±45° |
| Tailstock (U axis) | Max.10000mm/min | 250mm (240-490mm) | Max.4000mm/min | 250mm(130-380mm) |
| Machine Specification |
| Power Supply | 3AC 380V 30KVA | 3AC 380V 30KVA |
| CNC System | FANUC 0i-MF Plus | FANUC 0i-MF Plus |
| Floor Space (L × W × H) | 3970x3760x2380mm | 3150x2800x3010mm |
| Approx. Machine Weight | 5,000kg | 8,000kg |
